Mechanical
dimensions 362 x 267 x 184 mm (14.25 x 10.5 x 7.2")
weight 750 g (1.7 lb)
mounting pole mounting (kit included)
hardware
networking interface (1) 10/100 mbe rj45 port
power method passive poe 2-pair (4, 5+; 7, 8 return)
power supply 24v, 0.2a poe adapter (included)
supported voltage range 22–27v dc
max. power consumption 7w
esd/emp protection air/contact ± 24kv
etsi specification en 302 326 dn2
shock and vibration etsi300-019-1.4
rohs compliance yes
ambient operating temperature -40 to 70° c (-40 to 158° f)
ambient operating humidity 5 to 95% noncondensing
certifications fcc, ic, ce
software
operating frequency worldwide: 5150 - 5875 mhz
usa: 5725 - 5850 mhz
output power 25 dbm
gain 23 dbi
max. vswr 1.5:1
