NCTS Online Pure Sine Wave Nu6k16 Ups (6kva/4.8kw 12v/7a*16)

+1

UPS (Uninterruptible Power Supply)

Type

NCTS

Brand

NU6K16 UPS

Model

2

Number of Outlets

7Ah

Battery Capacity

4800watts

Wattage

6000VA

UPS Power

12 V

Voltage

Brand New

Condition

Store address

Greater Accra • Avenor Area

Abeka post office

Closed

• Mon - Sat, 09:00-18:00

Rated output capacity 6KVA/4.8KW Rated voltage 220VAC Input voltage range 120-275VAC±5 Input frequency range (45-55)±0.5Hz Bypass voltage 80VACx (1±5%)-285VACx (1±5%) Battery group voltage 192V Battery method Internal Battery capacity & quantity 12V 7ah X16 PCS Backup time (half/full) half load≥10 minutes, full load≥5minutes (standard) Maximum input current when power on <150% of rated current Battery charging time 5hours can charge to 90 %( standard) Output voltage 220VAC±1 %( invert output) Output frequency 50±5Hz (when AC input is normal) 50Hz±1% (when ac in out is abnormal) Wave form sine wave THD<3 %( linear load) sine waveTHD<8 %( Nonlinear load) Output power factor 0.8 Overload Protection 105-125% ,Transfer to Bypass after 1 Min Output current peak coefficient 03:01 Transfer time between AC and Battery 0ms
