Compatible for all huawei / zte modems with antenna slot
like: huawei b310, b311, b315, b525, b52, b618, b612, b715 lte router with antenna port, bolt helios bl-100, bolt b310 / xl home, bolt e5172, etc.
high performance: lte signal boost 3-7 db
one for two: one smart antenna = two traditional antennas
one for all: wide frequency range compatible with all huawei cpe
plug & play flexible installlation, fit for different scenarios
range frequency: 698-960 mhz / 1427-1500mhz / 1710-2690mhz / 3400-3800mhz
mswr: < 2.0
impedance input: 50ohm
peak gain: 6-7dbi (not including cable loss) / 3-4dbi (inclusudes cable loss)
polarization: vertical.
azimuth beam pattern: omnidirectional
maximum power input: 4w
type: 2 sma-male connector
cable: 5m
size: 170mm x 170mmx31.8mm
antenna color: white
installlation: desktop mounting, wall mounting
