Ripple & noise: 80mv
dc adjustable range: ±10% rated voltage
voltage tolerance: ±2.0%
line regulation: ±0.5%
load regulation: ±1%
setup,rise time,hold up time:200ms,50ms, 20ms/230vac
ac input
ac voltage range: 100-240vac
frequency range: 47-63hz
efficiency:>84%
ac current: 0.86/115v 0.4a/230v
ac inrush current: 20a/115v 40a/230v
leakage current< 0.5ma /240vac
protection
over-load: 105%-150% hiccup mode,auto-recovery
over-voltage: 115%-135% cut off the output,auto-recovery
over-temp. : shut down o/p voltage, auto-recovery
environment
working temp.: -10~ +60c° (refer to output load derating curve)
working humidity:20 ~ 90% rh, non-condensing
storage temp.: -10~ +60c°
storage humidity: 10 ~ 95% rh
safety
isolation resistance:i/p-o/p,i/p-fg,o/p-fg:100m ohms/500vdc / 25c°/ 70% rh
withstand voltage: i/p-o/p:3kvac i/p-fg:1.5kvac o/p-fg:0.5kvac
