Capacity (cooling, kw) 6
energy efficiency
eer (cooling, w/w) 3.51
noise level
noise level (indoor, high/low, dba) 44/30
sound power (outdoor, high, dba) 54
electrical data
power source(φ/v/hz) 1/230/50
power consumption(cooling, w) 1,710
operating current(cooling, a) 8
physical specification
net dimension (indoor, wxhxd, mm*mm*mm) 1,065 x 301 x 294
net dimension (outdoor, wxhxd, mm*mm*mm) 880 x 648 x 310
net weight (indoor, kg) 13.2
net weight (outdoor, kg) 41.7
technical information
piping length (max, m) 30
piping height (max, m) 15
svc valve (liquid (odxl)) 6.35
svc valve (gas (odxl)) 15.88
moisture removal (l/hr) 2.5
air circulation (cooling, m3/min) 21
