Tsm-405deg15m.20(11)
maximum power
maximum power voltage
maximum power current
open circuit voltage
short circuit current
(pmax)
(vmp)
(imp)
(voc)
(isc)
405w+3%*
40.5v
10.00a
49.2v+3%*
10.52a+4%*
maximum series fuse
20a
power selection
0 ~ 5w
maximum system voltage
iec1500v
*(considering lid, the power range of the certification authority)
electrical rating at stc am=1 5 irradiance =1000w/m? temp = 25 c
for field connections use minimum 4mm (no. 12awg)copper wires
insulated for a minimum 90 €
warning-electrical hazard
this module produces electricity when exposed to light.
follow all applicable electrical safety precautions.
ce
eu-28 weee compliant
