Output power capacity 20.0kwatts / 20.0kva
nominal output voltage 400v 3ph
nominal input voltage 400v 3ph
maximum input current 37.0a
output
max configurable power (watts) 20.0kwatts / 20.0kva
output voltage distortion less than 3 %
output frequency (sync to mains) 50 hz sync to mains, 60 hz sync to mains
other output voltages 380 v, 415 v
topology double conversion online
output voltage thd < 3% linear load
output voltage tolerance +/- 1.5 %
input
input frequency 45 – 65 hz
input voltage range for main operations 304 – 477v
input total harmonic distortion less than 3 % for full load
other input voltages 380 v, 415 v
input power factor at full load 0.99
batteries & runtime
battery type vrla
nominal battery voltage 240 v
battery slots empty 3
maximum available short
