Operation power voltage - 100-240v ac
allowable operating voltage - 85-264v ac
power source frequency - 50hz/60hz common use
driving method - quarts motor
power failure compensation - 100 hours
time precision - within +15seconds per month(at temperature 25°c)
program cycle - 24hours
consumption power - 110v ac 1w*220v ac 2w
circuit quantity - 1 circuit
circuit configuration - same circuit (voltage-applied contact output)
contact configuration - single pole. single-through
manual on/off - with on/auto/off switch
output contact capacity
resistance - 15a
incandescent lamp - 10a
induction(cos =0.7) - 12a
motor (cos=0.7) - 110v ac 750w * 220v ac 1500w
