48 10/100/1000mbps rj45 ports
innovative energy-efficient technology saves power consumption
supports mac address self-learning and auto mdi/mdix
standard 19-inch rack-mountable steel case
hardware features
standards and protocols ieee 802.3i, ieee 802.3u, ieee 802.3ab, ieee 802.3x
interface 48 10/100/1000mbps rj45 ports (auto negotiation/auto mdi/mdix)
network media 10base-t: utp category 3, 4, 5 cable (maximum 100m)
100base-tx/1000base-t: utp category 5, 5e or above cable (maximum 100m)
physical security lock no
power supply 100-240vac, 50/60hz
dimensions ( w x d x h ) 17.32*8.7*1.73 in.(440*220*44 mm)
mounting rack mountable
max. power consumption 28.21 w(220v/50hz)
max heat dissipation 96.20 btu/h
performance
switching capacity 96gbps
packet forwarding rate 71.4mpps
mac address table 16k
buffer memory 12mb
