D6-Smart Centurion Gate Motor

+1

2

Gates

Type

2000mm

Height

2000mm

Width

20kg

Weight

50mm

Thickness

Other

Opening Direction

Automatic

Opening

Bi-Parting Swing

Opening Type

Yes

Remote Opening

Green

Color

Plastic

Material

Brand New

Condition

Delivery

Across country

1-3 days

GH₵ 50 - 500

Store address

Greater Accra • Achimota

H/No. C320/22 ACHIMOTA ABOFU

Under bridge close to Mawarko

Open

• Mon - Sun, 09:00-17:00

Gate capacity ≤ 600 kg Gate length supported Up to 100 m Supply voltage 90–240 VAC @ 50 Hz Standby current (mains) 200 mA Battery system 24 V DC (2×12 V batteries) Charger output 1.3 A Max daily cycles Up to 150 operations Duty cycle (mains present) 50% Motor starting force 30 kgf Rated push force 17 kgf @ 35 m/min Motor current (rated) 13 A Battery-only operation ~209 cycles/day (power-saving), ~102 normal Full-day capacity ~183 (power-saving) / ~79 (normal) Receiver built-in NOVA code‐hopping, multichannel, up to 1500 remotes Receiver frequency 433.92 MHz I/O sink current I/O 1–4: 100 mA; I/O 5–6: 3 A (10 sec pulses) Safety sensing Electronic collision detection and auto-reverse Operating temperature –15 °C to +50 °C Enclosure protection IP55 (dust-tight, splash-resistant) Weight (boxed, no rack/battery) 9.1 kg
