Output
output power capacity 10.0kwatts / 10.0kva
max configurable power (watts) 10.0kwatts / 10.0kva
nominal output voltage 230v
efficiency at full load 94.0 %
output frequency (sync to mains) 50/60hz +/- 3 hz
other output voltages 220, 240
load crest factor 3 : 1
topology double conversion online
waveform type sine wave
output connections (1) hard wire 3-wire (h n + g) (battery backup)
bypass internal bypass (automatic and manual)
input
nominal input voltage 230v
input frequency 40 - 70 hz
input connections hard wire 3 wire (1ph+n+g)
input voltage range for main operations 176 - 300v
input voltage adjustable range for mains
operation
110 - 300 (half load)v
efficiency at full load 94.0 %
other input voltages 220, 240
